Motorola T5420 User's Guide

Models T5320, T5410, and T5420@[email protected] Page 1 Friday, December 21, 2001 11:55 AM

Safety and General Information6• Pull off the road and park before making or answering a call if driving conditions so require.OPERATIONAL WARNINGS• F

Safety and General Information7• BLASTING CAPS AND AREASTo avoid possible interference with blasting operations, turn off your radio when you are near

Safety and General Information84. Never alter the AC cord or plug provided with the unit. If plug will not fit the out-let, have proper outlet install

9Getting StartedGetting StartedTurning On/Off Your RadioRadio EtiquetteYour radio has multiple Channels shared on a “take turns” basis; other groups m

Diagram of Your Radio10Diagram of Your RadioUse P to:• Turn power on/off• Adjust volumeLED Indicator LightUse M to: • Talk on the radio• Save a settin

11PowerPowerBatteriesT5320, T5410, and T5420 radios operate with 3 AA Alkaline batteries or a NiCd rechargeable battery. A Rechargeable Upgrade Kit, m

Power12Battery LifeThe following chart lists the approximate battery life during Two-way use* for AA Alkaline and NiCd batteries.*Two-way use is defin

13Power6. Slide the radio into one of the Desk Stand charging pockets facing forward. The red light will glow if the radio is properly inserted.7. T

Talking and Listening14Talking and ListeningTo communicate, all radios in your group must be set to the same Channel (1-14) and Interference Eliminato

15Talking and ListeningChannel1. With radio On, press \ , Current Channel will begin to flash. 2. Use [ and ] to change Channel while flashing.3. Pr

6864110r10o.book Page 2 Friday, December 21, 2001 11:55 AM

Talking and Listening16Monitor ButtonPressing and holding J (T5410) or Q(T5320 and T5420), lets you hear the radio’s volume level when you are not re

17Talking and ListeningKeypad LockTo avoid accidentally changing radio operation, press \ for 3 seconds. Now you will see the f icon. This sequence l

Alerts18Scan AdvanceIf scan stops on a Channel that you don’t want to listen to, briefly press either the [ and ] to resume scanning for the next act

19AccessoriesTo Set the Call Tone• With the radio on, press \ until E appears in the upper right portion of the display. Current Call Tone setting 0-

Accessories20Hands-Free Use/VOX With Compatible VOX Accessories (T5420 Only)VOX allows you to transmit “hands-free” by talking while using VOX accesso

21AccessoriesBelt-clip(Included)Motorola T5320, T5410, and T5420 radios come with a swivel belt-clip. Front Cover (Included)Your radio has a removable

Troubleshooting22There are many accessories (sold separately) available for T5320, T5410, and T5420 radios. For more information refer to the brochure

23TroubleshootingHearing Other Conversation or Noise on a ChannelShared Channel may be in use, try another.Set Eliminator Code to 0 on a T5410 or T542

Use and Care24Use and CareIf the radio gets wet...To clean the radio, use a soft damp cloth.Do not immerse in water.Do not use alcohol or cleaning sol

25Limited WarrantyLimited Warranty for Motorola Personal Communications Products and Accessories Purchased in the United States and CanadaI. What This

IntroductionIntroductionMotorola Talkabout T5320, T5410, and T5420 radios operate on Family Radio Service (FRS) designated frequencies. This license-f

Limited Warranty26• Limited Lifetime Warranty Exception. The warranty is a limited lifetime warranty for the lifetime of ownership by the first end-us

27Limited WarrantyYou will receive instructions on how to ship the Products to Motorola or our designated resource. If instructed to ship the Products

Limited Warranty28• Rechargeable batteries that: (a) are charged by other than the Motorola-approved battery charger specified for charging such batte

29Limited WarrantyFlat-rate repair rates may apply to Products not covered by this warranty. To obtain information about Products needing repairs that

Limited Warranty30Products directly infringe a United States patent. Our obligation is conditioned on: (a) you notifying us promptly in writing when y

31Limited WarrantyTo obtain information on Motorola Personal Communications Products, including warranty service, accessories and optional Extended Wa

FCC License32FCCFCC License Not RequiredChanges or modifications not expressly approved by Motorola may void the user’s authority granted by the FCC t

33Export Law AssurancesPatent InformationThis product is manufactured under one or more of the following United States patents: 5896277 5894292 586475

Notes346864110r10o.book Page 34 Friday, December 21, 2001 11:55 AM

MOTOROLA, the Stylized M Logo, TALKABOUT, and all other trademarks indicated as such herein are trademarks of Motorola, 6864110r10o.book Page 37 Fr

ContentsSafety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1Getting Started . . . . . . . . . . . . . . . . . . . . . .9Turning On/Off Y

38MOTOROLA, the Stylized M Logo, TALKABOUT, and all other trademarks indicated as such herein are trademarks of Motorola, Inc. ® Reg. U.S. Pat. &

Safety and General Information1Safety and General InformationIMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATIONREAD THIS INFORMATION BEFORE USING Y

Safety and General Information2• American National Standards Institute (ANSI) / Institute of Electrical and Electronic Engineers (IEEE) C95. 1-1992• I

Safety and General Information3DO NOT hold the antenna when the radio is “IN USE.” Holding the antenna affects call quality and may cause the radio to

Safety and General Information4ELECTROMAGNETIC INTERFERENCE/COMPATIBILITYNote: Nearly every electronic device is susceptible to electromagnetic inter

Safety and General Information5Persons with pacemakers should:• ALWAYS keep the radio more than six inches (15 centimeters) from their pacemaker when
