A - 2 MC9090-G RFID Integrator Guide Supplement

Data Capture Options Omni-directional 1D and 2D imaging engine reads symbologies and captures

grayscale images and signatures with intuitive laser aiming.

Gen2 tags

Laser Decode Capability Code 39 Code 128 Code 93

Codabar Code 11 Discrete 2 of 5

Interleaved 2 of 5 EAN-8 EAN-13

MSI UPCA UPCE

UPC/EAN supplementals Coupon Code Trioptic 39

Webcode RSS-14 RSS Limited

RSS Expanded

MC909X with Windows Mobile 5.0 and OEM Version 01.39.0001

Imaging Decode Capability Code 39 Code 128 Code 93

Codabar Code 11 Interleaved 2 of 5

Discrete 2 of 5 MSI EAN-8

EAN-13 UPCA UPCE

UPC/EAN supplementals Coupon Code Trioptic 39

Webcode TLC39 Composite AB

Composite C Micro PDF-417 PDF-417

Macro PDF-417 (Macro) Micro PDF-417 QR Code

RSS Expanded RSS Limited RSS-14

Data Matrix Maxi Code US Postnet

US Planet UK 4-state Australian 4-state

Canadian 4-state Japanese 4-state Dutch Kix

MC909X with Windows Mobile 5.0 and OEM Version 01.39.0001

User Environment

Operating Temperature -4°F to 122°F (-20°C to 50°C)

Battery Charging

Temperature

32° to 104° F / 0° to 40° C ambient temperature range

Storage Temperature -25°F to 160°F (-40°C to 70°C)

Humidity 5% to 95% non condensing

Drop Specification Multiple 6 ft.(1.8m) drops to concrete across operating temperature range

Tumble 2,000 one-meter tumbles at room temperature (4,000 hits)

Environmental Sealing IP64

ESD +/-15kVdc air discharge

+/-8kVdc direct discharge

+/-8kVdc indirect discharge

RFID

Standards Supported EPC Generation 2 UHF

Table A-1

Technical Specifications (Continued)

Item MC9090-G RFID
